Flexure stages 8MTF2 are ideal for high precision device manipulation. This stage suits almost any micropositioning applications range, for example, from fiber launch systems for single-mode, multimode and polarization maintaining fibers as well as waveguide alignment, through to the manipulation of microstructures in bioscience. Fiber Coupling Stage of flexure compact block design with high-resolution motorized actuators ensures long-termed stability and good stiffness together with smooth motion without the severe limitations of sticking and friction. Fiber Coupling Flexure stages have a combination of overall size, travel, resolution, and low cost that makes them unique decision to meet the stringent requirements of photonics laboratory applications.

Ordering Information  #8MTF2 or #8MTFM

(Both models have same specifications. The only difference is that 8MTF2M is a "mirror" version of the 8MTF2 (placement of linear actuators is specularly  opposite).
