	Continuous rotation
	Very compact design
	No need to use extra adapter plate
	Version for vacuum
	Motorized version

The main advantage of this precision rotation stage is that it has very compact dimensions and low-profile together with the great aperture in the middle. This rotation stage has two modifications with different apertures: M27x1 or 30 mm. 7R150 doesn't need additional adapter plate to be mounted on any surface as it has 3 M6 holes on bottom. Click here for mini rotation stage which has even more compact design.
