STA-01-7 OM is a low-jitter, externally triggered, passively Q-switched diode-pumped solid-state SLM laser emitting pulsed radiation at the wavelength 1062.5 nm in a TEM₀₀ beam. Single pulse energy up to 20 µJ is available for 2 ns pulses. The laser can be operated in a single shot mode as well as repetitively switched up to 100 Hz.

*Beam waist is located 30±1 mm right the output flange.

 - Features

. Pulse Delay Time <5 µs

. Highly reliable fiber-coupled laser diodes are incorporated into a home-built digital controller 12STAD-01-7.

. By increasing the pulse delay time the single pulse energy can be brought to a mJ range.

. USB interface

. Interlock Circuit

- Applications

. LIBS

. LIPS

. Thermal or Plasma Ignition

. Mass Spectrometry
