STA-01-YLF
  • STA-01-YLF
제조사 STANDA Ltd
STA-01-YLF

. 1047 nm, 500 ps, peak power 1 MW, TEM00 and SLM

The Passive Q-Switched Laser STA-01-YLF is a sub-nanosecond passively Q-switched diode-pumped Nd:YLFmicrolaser. Depending on model the laser can be operated at wavelength of 1047 nm or 1053 nm. The laser delivers up to 1 mJ pulses with pulse duration as low as 350 ps and peak power exceeding 1MW in a TEM00 beam. Built-in frequency generator allows the STA-01-8-1047 to operate at repetition rates from single shot up to 500Hz, external TTL triggering is also standard option for this model. Laser output can be doubled (523nm) and tripled (349 nm) upon request. customization of STA-01-YLF series lasers is possible and welcome.

- Applications

. Materials processing

. LIPS

. Biophotonics

. Semiconductor inspection

. Marking

. Microprocessing

. LIBS

. Nonlinear optics

. Photoacoustic spectroscopy
