8MR191 - Motorized Rotary Stage
Motorized Rotary Stage
== 옵션선택 ==
8MR191 - Motorized Rotary Stage
목록
Specification
8MR191-28
8MR191-30
Stage without motor. We are able to equip our stage with any your provided stepper or dc motor.
View motor install guide
8MR190V-VSS42
Specifications same as non-vacuum model.
Compatible with 10
-6
Torr vacuum.
Specifications
8MR191-28
8MR190V-VSS42
8MR191-DCE
Rotation range
360°
360°
360°
Resolution in full step
0.6arcmin (0.01°)
0.6arcmin (0.01°)
Max.rotation speed
8turn/min
2turn/min
Backlash
0
0
0
Wobble
0.5arcmin
0.5arcmin
0.5arcmin
Eccentricity
10µm
10µm
10µm
Load capacity
Horizontal
10kg
10kg
Vertical
2kg
2kg
Torque
1Nm
0.6Nm
Weight
1kg
1kg
Motor
28
VSS42
Recommended controllers
8SMC5-USB
8DCMC1-USB
8SMC5-USB
Mechanical home reference switch
1, pushed is "closed"
Model
8MR191-28
8MR191-4247
8MR191-4233
8MR191-ZSS43
8MR190V-VSS42
Connector
HDB15(M)
DB9(M)
DB9(M)
DB9(M)
HDB15(M)
Cable
integrated
1.6 m length
on request
on request
on request
2 m length, non vacuum
