7T184-13 - Ball Bearing Translation Stage
  • 7T184-13 - Ball Bearing Translation Stage
제조사 STANDA Ltd
7T184-13 - Ball Bearing Translation Stage

Ball Bearing Translation Stage

목록
7T184-13 (2 pieces) stacked in XY coordinates 7T184-13 (2 pieces) and 7VT174-10 stacked in XYZ coordinates; 7VT174 (vertical translation stage) on top

7T184-13 (2 pieces) and 7VT174-10 stacked in XYZ coordinates; 7VT174 (vertical translation stage) at the bottom

7T184-13 (3 pieces) stacked in XYZ configuration 2AB174 Angle Bracket which is used for stacking Z axis while constructing XYZ stage and using only 7T184-13 ball bearing translation stages

3UBP-03 Universal Base Plate is required to fix the stages to a flat surface e.g. optical table.   Reach travel minimum and maximum to gain access to four M3 mouting holes for direct mounting of the stage.

Custom request with bigger knob 7T184-13-001
