Micro Translation Stage 7T128 provides smooth, precise single axis movement. M2 and M4 mounting holes are provided. Angle brackets 2AB128 allow to stack the stages for X-Y and X-Y-Z motion. The base and the platform are produced from the black anodized aluminium.

2AB128 7T128 XY 7T128 XYZ

Angle Bracket 2AB128 Usage of angle bracket 2AB128

7T128-9S35-5 (with micrometer 9S35-5 installed) 3BP7T128 Base Plate for stacking the translation stages 7T128 7T228T and rotation stage 7R128 to optical tables, breadboards or to another stages.
