Motorized Laser Beam Attenuator is a computer controlled laser beam attenuation device. It attenuates free space laser beam/pulse continuously without introducing additional energy fluctuations. Despite stand alone device look, Watt Pilot is very compact and it can be easily integrated in custom optical system.
| MODEL |
High Power Enhanced performance |
High Power |
Medium Power Enhanced performance |
Medium Power |
| Configuration |
λ/2 ZO Waveplate + 2x Brewster type thin film polarizers |
λ/2 LO Waveplate + 2x Brewster type thin film polarizers |
λ/2 ZO Waveplate + Polarizing cube |
λ/2 LO Waveplate + Polarizing cube |
| Operational wavelenght range |
+/-10 nm |
+/-2 nm |
+/-10 nm |
+/-2 nm |
| Damage threshhold |
>5 J/cm2 |
>5 J/cm2 |
>0.3 J/cm2 |
>0.3 J/cm2 |
| Time between min and max attenuation |
3 sec |
| Resolution |
41.54 arcsec/step |
| Step accuracy in full rotation |
± 4 steps |
| Backlash |
± 4 steps |
| Series |
CA, mm |
Optimization mode |
Attenuation range |
Wavelength, nm |
Code |
| Standard |
10 |
Transmission/Reflection |
0.5 - 95% for p-pol beam |
355 ± 10 |
10MAPF3-STR-10-355W |
| 532 ± 10 |
10MAPF3-STR-10-532W |
| 633 ± 10 |
10MAPF3-STR-10-633W |
| 780 ± 10 |
10MAPF3-STR-10-780W |
| 850 ± 10 |
10MAPF3-STR-10-850W |
| 1064 ± 10 |
10MAPF3-STR-10-1064W |
| 1310 ± 10 |
10MAPF3-STR-10-1310W |
| 1550 ± 10 |
10MAPF3-STR-10-1550W |
| 532 ± 2 |
10MAPF3-STR-15-532 |
| 633 ± 2 |
10MAPF3-STR-15-633 |
| 780 ± 2 |
10MAPF3-STR-15-780 |
| 850 ± 2 |
10MAPF3-STR-15-850 |
| 1064 ± 2 |
10MAPF3-STR-15-1064 |
| 1310 ± 2 |
10MAPF3-STR-15-1310 |
| 1550 ± 2 |
10MAPF3-STR-15-1550 |
| 532 ± 10 |
10MAPF3-STR-15-532W |
| 633 ± 10 |
10MAPF3-STR-15-633W |
| 780 ± 10 |
10MAPF3-STR-15-780W |
| 850 ± 10 |
10MAPF3-STR-15-850W |
| 1064 ± 10 |
10MAPF3-STR-15-1064W |
| 1310 ± 10 |
10MAPF3-STR-15-1310W |
| 1550 ± 10 |
10MAPF3-STR-15-1550W |
| |
| Enchanced |
15 |
Transmission |
0.3 - 95% for p-pol beam |
266 ± 5 |
10MAPF3-ETR-266 |
| 355 ± 5 |
10MAPF3-ETR-355 |
| 400 ± 5 |
10MAPF3-ETR-400 |
| 515 ± 5 |
10MAPF3-ETR-515 |
| 532 ± 5 |
10MAPF3-ETR-532 |
| 780 ± 5 |
10MAPF3-ETR-780 |
| 780-820 |
10MAPF3-ETR-800W |
| 800 ± 5 |
10MAPF3-ETR-800 |
| 1020-1040 |
10MAPF3-ETR-1030W |
| 1064 ± 5 |
10MAPF3-ETR-1064 |
| 1550 ± 5 |
10MAPF3-ETR-1550 |
| Reflection |
0.3 - 99% for s-pol beam |
266 ± 5 |
10MAPF3-ERE-266 |
| 355 ± 5 |
10MAPF3-ERE-355 |
| 400 ± 5 |
10MAPF3-ERE-400 |
| 515 ± 5 |
10MAPF3-ERE-515 |
| 532 ± 5 |
10MAPF3-ERE-532 |
| 780 ± 5 |
10MAPF3-ERE-780 |
| 800 ± 5 |
10MAPF3-ERE-800 |
| 1064 ± 5 |
10MAPF3-ERE-1064 |
| 1550 ± 5 |
10MAPF3-ERE-1550 |
| Broadband reflection |
0.5 - 98% for s-pol beam |
800 ± 20 |
10MAPF3-EBR-800W |
| 1030 ± 20 |
10MAPF3-EBR-1030W |
| |
| Ultrafast |
15 |
Reflection mode |
4 - 96% |
800 ± 25 |
10MAPF3-URE-800 |
| Reflection contrast mode |
0.1 - 70% |
800 ± 25 |
10MAPF3-URC-800 |
| Reflection mode |
4 - 96% |
800 ± 50 |
10MAPF3-URE-800W |
| Reflection contrast mode |
0.1 - 70% |
800 ± 50 |
10MAPF3-URC-800W |
