The Dovetail Translation Stage is miniature, ideal for use in applications where space is limited. The design uses a precision M4x0.25mm pitch lead screw for smooth linear positioning along the entire range of travel. The Moving platform is lockable. Various application accessories are also available.
Custom stage with increased sensitivity actuators 7T25-10.08.01. Adjustment can be done using hex screw or, more conveniently and with higher sensitivity by using 6 holes in head of screw
Two Axis Tilt Stage 6TS29-21
Custom Base Plate
|7T25-10 XYZ using custom accessories
Base Plate 3BP7T25-10
Angle Bracket 2AB7T25-10
